Particle Size and Shape Analyzer CAMSIZER® XL

Particle Size and Shape Analyzer CAMSIZER XL
Contact usCitations
Request a quote
Create PDF

Language:

The CAMSIZER XL by Microtrac is a large particle size and shape analyzer that can measure particles ranging in size from 160 to 135,000 µm.


  • Characterizes more than 40 morphological parameters of your material including 3D
  • Non-contact measurement of dry particles ranging in size from 160 – 135,000 µm
  • Customizable sample introduction
  • Analyses 100 images per second with high-speed, high-resolution camera
  • Enclosed optical system which reduces downtime for maintenance


Click to view video

Product Video

Features

  • By having the ability to measure more than 40 parameters including 15 size, 13 shape / form, 3 surface roughness, density, transparency, and 3D in one analysis, the CAMSIZER XL provides users with superior analysis capability that enables quick and confident decision-making regarding product quality
  • Industry leading size range provides the user with greater analysis flexibility to measure a variety of materials
  • The high-speed, high-resolution camera ensures multiple, vivid pictures of your material are collected which result in accurate analysis
  • Engineered to be able to handle the toughest environments, the CAMSIZER XL is adaptable for any lab setting
  • The self-cleaning mechanism allows a user to spend less time cleaning the instrument, and more time being productive

Typical Applications

Used in various fields such as: aggregates , building materials, fertilizers, food, geology / mining, glass beads, ...

cement

cement

fertilizers

fertilizers

wood chips

wood chips

To find the best solution for your particle characterization needs, visit our application database

Application Database
.

Citations

Our instruments are recognized as the benchmark tools for a wide range of application fields in science and research. This is reflected by the extensive citations in scientific publications. Feel free to download and share the articles provided below.

Technical Data

Measuring principleDynamic Image Analysis (ISO 13322-2 & 9276-6)
Measuring range160 µm - 135 mm
Measurement parametersThe patented 3D measurement follows the ISO 13322-2
Measurement rate> 100 images/s
Scale factor (µm / pixel)160 µm / pixels
Camera pixel layout2560 x 2048 pixels, 62 fps at max resolution
Light sourceStroboscopic light
Electrical110-230 V / 50-60 Hz
Power consumptionApprox. < 100 Watt
Sample amount> 2kg (depending on application)
Measuring time~ 1 - 5 minutes (depending on application)
Physical specificationsAluminum and stainless steel
Dimensions (W x H x D)400 x 1229 x 1693 mm
Weight~ 70 kg

Content may be subject to modifications or corrections
